AURON HFP-48 - Dielectric Fluid for Immersion Cooling
Dielectric Heat Transfer Fluid for Two-Phase Immersion Cooling
AURON HFP-48 is a fluorinated, dielectric heat transfer fluid designed for demanding electronics and industrial cooling applications. It combines efficient heat transfer with excellent electrical insulation properties, enabling the direct cooling of live electronic components.
With a boiling point of 48 °C, AURON HFP-48 is particularly suitable for two-phase immersion cooling systems, as well as applications in data centers and power electronics.
Your benefits at a glance
✔ Dielectric – suitable for direct cooling of live electronics✔ Non-flammable – no flash point
✔ Low viscosity – supports high flow rates and reduces pumping energy requirements
✔ High chemical and thermal stability
✔ Low GWP and zero ODP
✔ Broad material compatibility
✔ Wide operating temperature range
Why AURON HFP-48?
For Direct Cooling of Live Electronics
AURON HFP-48 provides a dielectric strength of 24 kV/mm, making it suitable for applications where electronic components are immersed directly in the cooling fluid. Its low viscosity enables high flow rates, while good surface wetting properties support efficient heat transfer.
The typical operating temperature range specified in the technical data sheet is approximately -70 °C to +40 °C.
Designed for a Wide Range of Applications
AURON HFP-48 is suitable for numerous industrial applications:
Two-Phase Immersion Cooling
AURON HFP-48 is suitable for systems in which heat is absorbed directly from electronic components through evaporation of the fluid.
Data Centers
Its dielectric properties enable the direct cooling of electronic components and support efficient thermal management concepts.
Power Electronics
Suitable for applications with high power densities and correspondingly high requirements for heat dissipation and electrical insulation.
Other Applications
AURON HFP-48 can also be used as a foam insulation additive.
Material Compatibility
Suitable metals:
|
Suitable Plastics:
|
Suitable Elastomeres:
|
For critical applications, we generally recommend conducting a material test under actual process conditions.
Technical Data
| Property | Value |
| Chemical type | Heat transfer fluid |
| ppearance | clear, colourless |
| Boiling Point | 48°C |
| Flash Point | none |
| Pour Point | -80°C |
| Density 25°C | 1,6 kg/l |
| Molecular Weight | 300 g/mol |
| Specific Heat Capacity | 1,13 kJ/(kg·K) |
| Heat of Vaporization | 98 kJ/kg |
| Vapor Pressure | 3.47 kPa |
| Water Solubility | 0.649 mg/L at 22.3 °C |
| Dielectric Strength | 24 kV/mm at 50 Hz |
Safety and Environment
AURON HFP-48 has an ODP of 0 and a GWP of less than 100–120. The fluid is non-flammable and can generally be recycled or reused.
Its low viscosity can help reduce the energy consumption of pumping systems. In addition, AURON HFP-48 offers a long service life and stable performance, with the potential to reduce maintenance requirements and downtime.
Consulting for your application
Our team will assist you in selecting the right fluid and support you through material testing, process evaluation, and series production.
Manufacturer: | Puretecs |
Container type: | 25-kg plastic canister |
Property: | non-flammable, dielectric, chemically stable, ODP 0 |
Application: | Heat Transfer, Immersion Cooling |
Suitable for: | Electronics, semiconductor equipment, data centers, specialized processes |
Datasheet: |
